Lithium lifepo4 golf cart batteries 48v 36v 51.2V 72V 50Ah 100Ah 105Ah 150Ah 160Ah 200Ah

Inquire Now

Description

Anode: LFP
Brand: NOVACELL
Model: NV-GC48105P
N.W.: 50g
Charge current: 25A
Discharge current: 50A
Peak discharge current: 100A
Housing: SPCC

Advantages

Battery type: LiFePO4
LiFe Cycle: 5000+ cycles
Warranty: 5 years
Quality: Grade A
IP Rate: IP65
Rapid charge: 2.5Hrs
Design life: 10 years
Certificate: CE RoHS IEC62133 UN38.3

Application

Golf cart
48v golf cart
Bluetooth golf cart
EVs
Carava
Club bus resort vehicles
Electric golf cart
Golf carts 2 seater

Specification

Electrical Characteristics	Voltage	48V
	Nominal Voltage	51.2V
	Nominal Capacity	105Ah
	Energy	5.37kWh
	Battery type	LiFePo4
	Cycle Life	5000+ cycles
	Months Self Discharge	≤3% per month at 25℃
Standard Charge	Charge Voltage	58.4±0.2V
	Charge Mode(CC/CV)	At 0℃~45℃, charged to 58.4V at constant current of 0.2C5A, and then change continuously with constant voltage of 58.4V until the current was not more than 0.02C5A.
	Standard Charge Current	25A
	Max.Charge Current	50A
Standard Discharge	Standard discharge Current	50A
	Max. Discharge Current	50A
	Peak Discharge Current	100A(30S)
	Disxcharge Cut-off Voltage	40.0V
Environmental	Charge Temperature	0℃~45℃
	Discharging	-10℃~60℃
	Storage temperature	-5℃~35℃
	Storage Humidity	≤75% RH
	Water Dust Resistance	IP65
Mechanical	Cell	16S1P
	Housing	SPCC
	Dimension(LWH*)	550320280(mm)
	Communication interface	RS485 / CAN
	IP Rate	IP65
	Weight	Approx. 50Kg

More details

Lithium lifepo4 golf cart batteries 48v 36v 51.2V 72V 50Ah 100Ah 105Ah 150Ah 160Ah 200Ah, the golf cart battery is designed to offer a seamless and reliable replacement for your electric golf cart, with designed life 10 years, minimal maintenance requirements and superior performance, it has features of RS485/CAN communication, IP65 waterproof, 5 years warranty and Light weight

Photo Exhibition
