Li-ion Polymer Battery

Inquire Now

Shape, dimension, voltage, capacity and current can be customized
Light weight, high density, safety and long life cycle
Protection pcb board, cable and connector are included
Multiple series and parallel battery pack
Low self-discharge rate
Eco-friendly

Advantages

1. Shape, dimension, voltage, capacity and current can be customized

2. Light weight, high density, safety and long life cycle

3. Protection pcb board, cable and connector are included

4. Multiple series and parallel battery pack

5. Low self-discharge rate

6. Eco-friendly

Application

1. Tracker, heated golves, heated clothes, consumer electronics, earphones, electronic scale, mini fan, earphone headset, shoes, speaker, fishing light, india power bank, smart bracelet, medical device, led light, sensor, keyboard, record pen, smart card, heated jackets,

2. Scooter, strips, POS machine, water meter, solar street lights, solar lamps, electronic lock, CCTV Camara, beauty instruments, medical instruments, Vaccum cleaner, router, camping lantern, emergency light, toys, Robot lawn mover, flashlight,

3. Ebike, energy storage, solar energy, boats, marines, golf carts,solar system, camping light, wheelchair, communication tower, home power system

Specification

Series	Model	Typical Capacity	Min. Capacity	Impedance	Nominal Voltage	Dimension			Weight	Tab Distance
Series	Model	/mAh	/mAh	/mΩ	/V	Max	Max	Max	g	mm
XX1225	031225	55	50	≤500	3.7	3.2	12.5	25.5	1.2	3.5~5.5
	381225	80	74	≤300	3.7	3.9	12.5	25.5	1.6	3.5~6.5
	041225	90	85	≤350	3.7	3.9	12.5	25.5	1.7	3.5~6.5
	051225	110	100	≤280	3.7	5.0	12.5	25.5	2.6	3.5~5.5
	061225	100	105	≤250	3.7	6.2	12.5	25.5	2.7	3.5~5.5
	651225	130	130	≤280	3.7	6.7	12.5	25.5	2.7	3.5~5.5
XX1230	031230	75	70	≤400	3.7	3.20	12.5	30.5	1.5	3.5~5.5
	351230	85	75	≤350	3.7	3.7	12.5	30.5	1.9	3.5~5.5
	041230	100	92	≤300	3.7	4.2	12.5	30.5	2.0	3.5~5.5
	451230	135	130	≤200	3.7	4.5	12.5	30.5	3.0	4~6
	051230	130	120	≤220	3.7	5.2	12.5	30.5	2.9	3.5~5.5
	551230	140	130	≤200	3.7	5.7	12.5	30.5	3.0	3.5~5.5
XX1235	031235	90	80	≤310	3.7	3.0	12.5	35.5	1.9	3.5~5.5
	041235	120	100	≤260	3.7	4.2	12.5	35.5	2.7	3.5~5.5
	451235	130	120	≤220	3.7	4.5	12.5	35.5	2.9	3.5~5.5
	051235	150	150	≤150	3.7	5.1	12.5	35.5	3.2	3.5~5.5
	551235	180	180	≤160	3.7	5.4	12.5	35.5	3.8	3.5~5.5
	061235	190	170	≤180	3.7	6.2	12.5	35.5	4.3	3.5~5.5
	651235	150	150	≤150	3.7	5.8	12.5	35.5	4.8	3.5~5.5
	071235	240	220	≤130	3.7	7.2	12.5	35.5	4.6	3.5~5.5
XX1730	031730	100	100	≤300	3.7	3.2	17.5	30.5	2.9	8±2
	451730	170	160	≤180	3.7	4.7	17.5	30.5	3.3	7±2
	451730	190	180	≤180	3.7	4.7	17.5	30.5	3.7	7±2
	051730	200	190	≤170	3.7	5.2	17.5	30.5	4.3	6±2
	551730	230	210	≤160	3.7	5.7	17.5	30.0	5.0	6±2
XX2025	032025	110	105	≤250	3.7	3.2	20.3	25.5	2.8	10.5~12.5
	042025	150	150	≤200	3.7	4.2	20.3	25.5	3.4	9~11
	422025H	180	170	≤200	3.7	4.4	20.3	25.5	3.9	9.5~11.5
	052025	180	160	≤200	3.7	5.2	20.3	25.5	3.9	7±2
	552025	240	200	≤150	3.7	5.7	20.3	25.5	4.6	7±2
	062025	250	250	≤150	3.7	6.2	20.3	25.5	4.9	7.5~9.5
	092025	360	340	≤120	3.7	8.8	20.3	25.5	6.8	6±2
XX2030	032030	130	120	≤260	3.7	3.2	20.5	30.5	2.2	8±2
	382030	180	170	≤170	3.7	4.0	20.5	30.5	3.9	8±2
	042030	180	180	≤180	3.7	4.2	20.5	30.5	4.8	9~11
	052030	260	260	≤150	3.7	5.2	20.5	30.5	5.2	9~11
	552030	280	260	≤120	3.7	5.7	20.3	30.5	5.6	8~10
	062030	300	280	≤110	3.7	6.2	20.3	30.5	6.0	7.5~9.5
	072030	400	400	≤120	3.7	6.9	20.3	30.5	6.8	7~9
	092030	500	500	≤90	3.7	9.2	20.3	30.5	8.5	4~6.5
XX2035	032035	160	160	≤180	3.7	3.2	20.3	35.5	3.4	10.5~12.5
	352035	190	180	≤150	3.7	3.7	20.3	35.5	4.3	8±2
	042035	240	220	≤150	3.7	4.0	20.3	35.5	4.6	9~11
	052035	320	310	≤100	3.7	5.0	20.3	35.5	6.4	8.5~10.5
	532035	340	320	≤100	3.7	5.5	20.3	35.5	6.7	7±2
	062035	400	400	≤100	3.7	6.3	20.3	35.5	8.1	7.5~9.5
	952036	650	650	≤80	3.7	9.5	20.3	36.0	11.7	4~6.5
XX2530	382530	240	230	≤150	3.7	4.0	25.5	30.5	4.6	13±2
	452530	300	280	≤100	3.7	4.5	25.5	30.5	6.0	12.5~14.5
	052530	400	370	≤150	3.7	5.5	25.5	30.5	6.8	13~15
	552530	380	350	≤80	3.7	5.7	25.5	30.5	7.8	10±2
	062530	450	450	≤80	3.7	6.5	25.5	30.5	8.1	12~14
	652530	440	420	≤100	3.7	6.7	25.5	30.5	8.8	9±2
	072530	450	460	≤100	3.7	7.0	25.5	30.5	8.3	10.5~12.5
	082530	600	600	≤80	3.7	8.2	25.5	30.5	13.0	9~11
XX2535	032535	220	220	≤180	3.7	2.9	25.3	35.3	4.2	12~14
	352535	260	240	≤150	3.7	3.7	25.3	35.3	5.0	12±2
	382535	320	300	≤120	3.7	4.0	25.3	35.3	6.8	12±2
	042535	320	320	≤120	3.7	4.2	25.3	35.3	6.8	11.5~13.5
	052535	400	390	≤100	3.7	5.2	25.3	35.3	8.1	11~13
	062535	500	500	≤90	3.7	5.8	25.5	35.5	9.7	12~14
	652535D2C	380	390	≤100	3.7	6.3	25.5	35.5	10.0	11.5~13.5
	072535	550	550	≤80	3.7	6.7	25.5	35.5	10.7	10~12
	082535	750	700	≤80	3.7	8.2	25.5	35.5	14.6	9~11
XX2540	452540	420	400	≤80	3.7	4.7	25.3	40.5	7.8	11.5~13.5
XX2540	062540	550	570	≤80	3.7	6.2	25.3	40.3	10.8	11~13
XX3040	033040	320	340	≤120	3.7	3.2	30.5	40.5	7.5	19~21
	053040	300	350	≤100	3.7	4.8	30.5	40.5	9.0	17~19
	053040	560	530	≤80	3.7	5.2	30.5	40.5	10.8	15±2
	523040	600	580	≤80	3.7	5.4	30.5	40.5	12.2	15±2
	553040	600	580	≤80	3.7	5.7	30.5	40.5	12.2	15±2
	753040	850	850	≤60	3.7	7.7	30.5	40.5	16.5	11±2
XX3048	033048	380	360	≤100	3.7	3.2	30.5	48.5	7.5	16±2
	353048	450	420	≤90	3.7	3.7	30.5	48.5	8.5	16±2
	043048	540	520	≤80	3.7	4.2	30.5	48.5	10.5	15±2
	053048	700	700	≤60	3.7	5.2	30.5	48.5	14.0	14±2
	553048	750	730	≤60	3.7	5.6	30.5	48.5		14±2
	063048	880	850	≤60	3.7	6.0	30.5	48.5	17.0	14±2
	073048	1000	950	≤60	3.7	7.2	30.5	48.5	19.5	13±2
	753048	1200	1050	≤60	3.7	7.8	30.5	48.5	21.5	13±2
	083048	1200	1150	≤50	3.7	8.5	30.5	48.5	23.5	12±2
	103048	1500	1400	≤50	3.7	10.3	30.5	48.5	29.0	10±2
XX3060	703060	1300	1200	≤50	3.7	7.2	30.5	60.5	25.3	13±2
XX3060	903060	1700	1700	≤40	3.7	9.2	30.5	60.5	33.1	12±2
XX3448	063448	850	820	≤60	3.7	6.0	34.5	48.5	17.0	18±2
	083448	1250	1200	≤50	3.7	8.0	34.5	48.5	24.5	16±2
	083448	1300	1300	≤50	3.7	8.2	34.5	48.5	25.3	16±2
	103448	1600	1600	≤50	3.7	9.2	34.5	48.5	31.0	14.5±2
XX3450	383450	650	620	≤60	3.7	4.0	34.5	50.5	12.8	20±2
	483450	820	800	≤60	3.7	5.0	34.5	50.5	15.5	19±2
	483450	900	880	≤70	3.7	4.8	34.5	50.5		20±3
	053450	850	800	≤60	3.7	5.2	34.5	50.5	16.8	19±2
	533450	1000	950	≤60	3.7	5.4	34.5	50.5	19.4	18±2
	053450HT	900	850	≤60	3.7	5.2	34.5	50.5	17.5	18±2
	063450L	850	850	≤60	3.7	5.8	34.5	50.5	17.8	17±2
	063450	1100	1050	≤60	3.7	6.2	34.5	50.5	21.5	17±2
	083450	1250	1200	≤60	3.7	8.0	34.5	50.5	24.5	14±2
	853450	1400	1450	≤50	3.7	8.3	34.5	50.5	27.3	15±2
	853450	1500	1400	≤50	3.7	8.8	34.5	50.5	29.0	15±2
	093450	1050	1050	≤50	3.7	8.8	34.5	50.5		14±2
	093450	1100	1080	≤50	3.7	9.3	34.5	50.5		14±2
	093450	1200	1150	≤50	3.7	9.0	34.5	50.5		14±2
	103450	1800	1800	≤40	3.7	10.0	34.5	50.5	35.0	14±2
XX3460	033560	600	580	≤80	3.7	3.3	35.5	60.0	11.5	21±2
	483560	1000	950	≤60	3.7	5.0	35.5	60.0		18±2
	063460	1250	1250	≤50	3.7	6.4	34.3	60.5		16±2
XX3759	033759	600	600	≤70	3.7	3.2	37.5	59.5	11.6	23±2
	043759	900	850	≤50	3.7	4.2	37.5	59.5	17.5	22±2
	053759HT	1100	1000	≤50	3.7	5.5	37.5	59.5	22.5	22±2
	053759	1200	1100	≤50	3.7	5.2	37.5	59.5	23.0	22±2
	583759	1400	1400	≤50	3.7	5.9	37.5	59.5		20±2
XX4050	384050HT	800	750	≤60	3.7	4.0	40.5	50.5	15.7	26±2
	054050	1000	900	≤50	3.7	5.2	40.5	50.5	19.5	25±2
	554050	1100	1000	≤50	3.7	5.7	40.5	50.5	21.5	24±2
	064050	1200	1150	≤50	3.7	6.2	40.5	50.5	23.0	23±2
	654050	1400	1300	≤50	3.7	6.7	40.5	50.5	27.0	23±2
	104050	2200	2200	≤40	3.7	10.0	40.5	50.5	42.5	18±2
XX5080	035080	1200	1100	≤50	3.7	3.2	50.0	80.5	23.0	35±2
	035080	1250	1220	≤40	3.7	3.2	50.0	80.5		35±2
	055080	2000	2000	≤35	3.7	5.2	50.0	80.5	38.0	33±2
	065080	2400	2400	≤40	3.7	6.2	50.5	80.5	46.0	18±2
	085080	3500	3500	≤40	3.7	8.0	50.5	80.5	65.0	31±2
XX50100	4050100	2050	2000	≤40	3.7	4.2	50.3	100.5		24±2
	0550100	2700	2650	≤30	3.7	5.2	50.3	100.5		34±2
	0750100	2500	2500	≤35	3.7	6.8	50.0	100.5		18±2
	0850100	4100	4000	≤35	3.7	8.1	50.0	100.5	77.0	30±2
XX6080	036080	1200	1300	≤50	3.7	3.7	60.5	79.5		24±2
	456080	1000	1000	≤50	3.7	4.0	60.5	79.5	30.0	31±2
	456080	1600	1600	≤40	3.7	4.0	60.5	79.5	40.0	31±2
	056080	2400	2400	≤40	3.7	4.8	60.5	79.5		36±2

Wire lead tolerated safety current

Gauge (AWG)	LDPE Synthetic Rubber Polyurea		LDPE SR-PLLA	PVC XLPVC Nylon	XLPE	PTFE
30	2		3	3	3	7
28	3		4	4	5	6
26	4		5	5	6	7
24	6		7	7	8	10
22	8		9	10	11	13
20	10		12	13	14	17
18	15		17	18	20	24
16	19		22	24	26	32
14	27		30	33	40	45
12	36		40	45	50	55
10	47		55	58	70	75
8	65		70	75	90	100
6	95		100	105	125	135
4	125		135	145	170	180
2	170		180	200	226	240
Safety temp.	80℃		90℃	105℃	125℃	200℃
Multi. Cable		Temp. Factor
2-5		0.8
6-15		0.7
16-30		0.5
