501230 401430 battery 3.7v 120mAh 125mAh 130mAh 135mAh 140mAh 145mAh 160mAh lipo rechargeable battery for smartlock

Inquire Now

Features

Anode: NCM
Brand: NOVACELL
Model: 501230P
Energy: 0.52Wh
Capacity: 120~145mAh
Voltage: 3.7V
Charge current rate: 1C
Discharge current rateL 1C
Cell dim.: T5*W12*L30mm
Working temp.: -20~60°C

Advantages

N.W.: 2.8g or less
Life cycle: 550+ cycles
OEM/ODM: available
Warranty: 13+ months
Quality: Grade A
Certificate: BIS KC CB CE RoHS FCC IEC UN38.3 MSDS

Application

Smartlock
Nickband
Electric scooter
Earphone

Specification

Electrical Characteristics	Nominal Voltage	3.7V
	Nominal Capacity	120mAh~150mAh
	Energy	0.52Wh
	Battery type	Lipo
	Cycle Life	550+ cycles
	Months Self Discharge	≤3% per month at 25℃
Standard Charge	Charge Voltage	4.2±0.2V
	Charge Mode(CC/CV)	At 0℃~45℃, charged to 4.2V at constant current of 0.2C5A, and then change continuously with constant voltage of 4.2V until the current was not more than 0.02C5A.
	Standard Charge Current	24mA
	Max.Charge Current	120mA
Standard Discharge	Standard discharge Current	24mA
	Max. Discharge Current	120mA
	Discharge Cut-off Voltage	3.0V
Environmental	Charge Temperature	0℃~45℃
	Discharging	-10℃~65℃
	Storage temperature	-5℃~35℃
	Storage Humidity	≤75% RH
	Water Dust Resistance	IP50
Mechanical	Cell	Singe cell + PCM
	Housing	Aluminum Foil
	Cell Dimension(LWH*)	T5W12L30mm
	PCM	TBA
	N.W.:	Approx. 2.4g

More details

501230 li polymer battery could be made up to 120mAh 125mAh 130mAh 135mAh 140mAh 145mAh and 160mAh, it's widely used in smartlock,nickband,electric scooter , earphone and ect.
