500kWh 600kWh 750kWh 800kWh 250KW HV solar lithium battery bank power for energy storage system

Inquire Now

Description

Battery type: LiFePO4
Model No.: NV-CES760KWH250KW
Grid type: On/Off/Hybrid
Dim.: 1400mm*2400mm * 2500mm
Weight: 7t
Comm: RS485/RS232/CAN
IP Rate: IP54
Cooling: Air/Liquid cooling

Advantages

Safe: Independent fire zone limited
Easy installation: Modular design for Parallel and expansion
Small area: 3.3 square meters
Easy lift: Modular design
Easy expansion: Modular design
Intelligent: Support connection with PCS
Real time monitoring: Through computer or phone
Warning: Fault and fault location records

Application

Energy storage
Energy storage system
Solar Storage
Homes energy
Commercial energy
Industrial energy
Wind Energy
UPS Energy backup

Specification

ELECTRICAL	Nominal Capacity	760.3kWh
	Recommended Voltage	1108.8-1425.6Vdc
	Rated Voltage	1267.2Vdc
	Max Charge Rate	0.5 P@25℃
	Max Discharge Rate	0.5 P@25℃
	Max Charge Power	380.1kW(0.5P)
ENVIRONMENTAL	Operating Temperature	-20~45℃
	Operating Humidity	0-95%
	Cooled	Liquid Cooled
	Fire Fighting System	Aerosol/Water
	Altitude	＜ 3000m
	Enclosure Protection Rating	IP54
COMMUNICATIONS	Communication	CAN、RS485、Ethernet
COMMUNICATIONS	Certification	C62477、IEC61000、IEC60730、IEC60356
STRUCTURAL	Dimensions(WDH)	1400mm×2400mm x 2500mm
	Weight	≈ 7t
	Life cycle	EOL 70% ≥6000

More Details

500kWh 600kWh 750kWh 800kWh 250KW HV solar lithium battery bank power for energy storage system is very popular for industrial commercial energy storage and home energy storage, this battery integrated MPPT, PCS, BMS, EMS, Fire fighting protection, Cooling system and ect., it's modular design, very easy to move, installation and expansion, it's fire constrained zone and Grade A cells can ensure it safe to run average 10+ years, this battery can be charged by PV, Electricity, Diesel and Wind, Output AC100-240V/380V 250/500KW, this battery can be customized according to different requirements
