48V 36V 60V 72V 100Ah 200Ah sodium ion golf cart golfcart electric lithium lifepo4 battery

Inquire Now

Features

Anode: LFP
Brand: NOVACELL
Model: NV-GC48200LFPP
N.W.: 95Kg
Charge current: 1C
Discharge current: 1-3C
Nominal voltage: 51.2V
Capacity: 210Ah

Advantages

Batterty type: LiFePO4
LiFe Cycle: 5000+ cycles
Charge time: 2.5Hrs
Warranty: 5 years
Maintenance: Free
Quality: Grade A
IP Rate: IP65
Certificate: CE RoHS IEC62133 UN38.3

Application

Golf Cart
Electric golf cart
Chinese golf carts
Golf push cart
Golf cart 6 seater
Golf cart car
4 seater golf cart
Golf carts 2 seater

Specification

Electrical Characteristics	Voltage	48V
	Nominal Voltage	51.2V
	Nominal Capacity	200Ah
	Energy	10240Wh
	Battery type	LiFePo4
	Cycle Life	5000+ cycles
	Months Self Discharge	≤3% per month at 25℃
Standard Charge	Charge Voltage	58.4±0.2V
	Charge Mode(CC/CV)	At 0℃~45℃, charged to 58.4V at constant current of 0.2C5A, and then change continuously with constant voltage of 58.4V until the current was not more than 0.02C5A.
	Standard Charge Current	100A
	Max.Charge Current	200A
Standard Discharge	Standard discharge Current	100A
	Max. Discharge Current	200A
	Peak Discharge Current	400A(30S)
	Disxcharge Cut-off Voltage	40.0V
Environmental	Charge Temperature	0℃~45℃
	Discharging	-10℃~60℃
	Storage temperature	-5℃~35℃
	Storage Humidity	≤75% RH
	Water Dust Resistance	IP54
Mechanical	Cell	16S1P
	Housing	Steel
	Dimension(LWH*)	895300255(mm)
	Communication interface	RS485 / CAN
	IP Rate	IP65
	Weight	Approx. 95Kg

Related Models

Voltage	Nominal Voltage	Capacity	Energy	Cycle life	Dimension(mm)	N.W.	Charge current	Current	Peak current	Housing	IP rate
36V	38.4V	105Ah	4.03kWh	5000 Cycles	470300280mm	40KG	50A	100A	200A(30S)	Steel	IP65
36V	38.4V	210Ah	8.06kWh	5000 Cycles	670300300mm	75KG	100A	200A	400A(30S)	Steel	IP65
48V	51.2V	105Ah	5.37kWh	5000 Cycles	550320280(mm)	50 KG	50A	100A	200A(30S)	Steel	IP65
		150Ah	7.68kWh	5000 Cycles	760300280(mm)	70 KG	70A	100A	200A(30S)	Steel	IP65
		210Ah	10.75kWh	5000 Cycles	895300255(mm)	95 KG	100A	200A	400A(30S)	Steel	IP65
		230Ah	11.77kWh	5000 Cycles	800300300(mm)	105 KG	100A	200A	400A(30S)	Steel	IP65
		280Ah	14.33kWh	5000 Cycles	960320300(mm)	130 KG	100A	200A	400A(30S)	Steel	IP65
		315Ah	16.12kWh	5000 Cycles	1000300300(mm)	145 KG	150A	300A	450A(30S)	Steel	IP65
60V	64V	105Ah	6.72kWh	5000 Cycles	520340270(mm)	60 KG	50A	100A	200A(30S)	Steel	IP65
		150Ah	9.60kWh	5000 Cycles	707430245(mm)	85 KG	70A	100A	200A(30S)	Steel	IP65
		230Ah	14.72kWh	5000 Cycles	840345270(mm)	130 KG	100A	200A	400A(30S)	Steel	IP65
72V	76.8V	105Ah	8.06kWh	5000 Cycles	600300300(mm)	70 KG	50A	100A	200A(30S)	Steel	IP65
		150Ah	11.52kWh	5000 Cycles	1000300300(mm)	100 KG	70A	100A	200A(30S)	Steel	IP65
		173Ah	13.28kWh	5000 Cycles	800420300(mm)	120 KG	80A	150A	300A(30S)	Steel	IP65
		210Ah	16.12kWh	5000 Cycles	1160320300(mm)	145 KG	100A	200A	400A(30S)	Steel	IP65
	73.6V	210Ah	15.45kWh	5000 Cycles	1160320300(mm)	135 KG	100A	200A	400A(30S)	Steel	IP65
	76.8V	230Ah	14.72kWh	5000 Cycles	840345270(mm)	130 KG	100A	200A	400A(30S)	Steel	IP65
	76.8V	315Ah	24.19kWh	5000 Cycles	710360275/ 1160320300(mm)	210 KG	150A	300A	600A(30S)	Steel	IP67
	73.6V	315Ah	23.18kWh	5000 Cycles	710360275/ 1160320300(mm)	205 KG	150A	300A	600A(30S)	Steel	IP68
	76.8V	346Ah	36.57kWh	5000 Cycles	800740300(mm)	135 KG	150A	300A	600A(30S)	Steel	IP68
		460Ah	35.32kWh	5000 Cycles	750740500(mm)	310 KG	200A	400A	800A(30S)	Steel	IP68
		520Ah	39.93kWh	5000 Cycles	650740500(mm)	350 KG	250A	400A	800A(30S)	Steel	IP68
96V	96V	210Ah	20.16kWh	5000 Cycles	710360275/ 1160320300(mm)	180 KG	100A	200A	400A(30S)	Steel	IP65
		315Ah	30.24kWh	5000 Cycles	710360275/ 1160320300(mm)	265 KG	150A	300A	600A(30S)	Steel	IP67
		420Ah	40.32kWh	5000 Cycles	710360275/ 1160320300(mm)	355 KG	150A	300A	600A(30S)	Steel	IP68
144V	144V	280Ah	40.32kWh	5000 Cycles	1050800300(mm)	355 KG	100A	200A	400A(30S)	Steel	IP65
		420Ah	60.48kWh	5000 Cycles	1000650300/ 1000800300(mm)	530 KG	150A	300A	600A(30S)	Steel	IP68
		520Ah	74.88kWh	5000 Cycles	1500360300/ 1500640300(mm)	660 KG	250A	300A	600A(30S)	Steel	IP68

LiFePO4 Lithium golf cart battery has 48V 36V 60V 72V 96V voltages with 105Ah 150Ah 173Ah 210Ah 230Ah 280Ah 315Ah 346Ah 420Ah 460Ah 520Ah capacity, the golf cart battery is RS485/CAN communication, IP65 waterproof, 5 years warranty and Light weight
