| Electrical Characteristics | Nominal Voltage | 51.2V |
| Nominal Capacity | 30Ah | |
| Energy | 1536Wh | |
| Battery type | LiFePo4 | |
| Cycle Life | 3500+ cycles | |
| Months Self Discharge | ≤3% per month at 25℃ | |
| Standard Charge | Charge Voltage | 58.4±0.2V |
| Charge Mode(CC/CV) | At 0℃~45℃, charged to 58.4V at constant current of 0.2C5A, and then change continuously with constant voltage of 58.4V until the current was not more than 0.02C5A. | |
| Standard Charge Current | 30A | |
| Max.Charge Current | 30A | |
| Standard Discharge | Standard discharge Current | 30A |
| Max. Discharge Current | 100A | |
| Disxcharge Cut-off Voltage | 32.0V | |
| Environmental | Charge Temperature | 0℃~45℃ |
| Discharging | -10℃~60℃ | |
| Storage temperature | -5℃~35℃ | |
| Storage Humidity | ≤75% RH | |
| Water Dust Resistance | IP54 | |
| Mechanical | Cell | 16S5P |
| Housing | Steel | |
| Dimension(L*W*H*) | 230mm*210mm*161mm | |
| Communication interface | RS485 / RS232 | |
| Weight | Approx. 13Kg |
12.8V 30Ah can be made by LFP or Li-ion cells, housing, dimension and current is customized, it can be used for golf carts, electric bikes, electric wheelchairs, electric tricycle and ect.
