12V 7Ah 9Ah 12Ah 15Ah 16Ah 20Ah rechargeable lithium ion polymer battery

Features

  • Anode: NCM
  • Brand: NOVACELL
  • Voltage: 12V
  • Capacity: 6~20Ah
  • Charge current rate: 1C
  • Discharge current rage: 1C 3C 5C 8C 10C
  • PCM: Included
  • Switch: Included
  • Indicator: Included
  • Connector: DC35135/DC5521/DC5525

Advantages

  • Weight: Light
  • Energy density: the highest
  • Switch/Button: Included
  • Indicator/Display: Included
  • Life cycle: 550+ cycles
  • Housing: Epoxy board+PVC
  • Cost: Cheap
  • Certificate: CE ROHS BIS KC UN38.3

Application

  • LED Light
  • UPS
  • Walkie talkie
  • Speaker
  • Advertising lightbox
  • CCTV
  • Fans
  • Sprayer

Specification

Electrical CharacteristicsNominal Voltage11.1V
Nominal Capacity20Ah
Energy222Wh
Battery typeLipo
Cycle Life550+ cycles
Months Self Discharge≤3% per month at 25℃
Standard ChargeCharge Voltage12.6±0.2V
Charge Mode(CC/CV)At 0℃~45℃, charged to 4.2V at  constant current of 0.2C5A, and then change continuously with constant voltage of
4.2V until the current was not more than 0.02C5A.
Standard Charge Current10A
Max.Charge Current20A
Standard DischargeStandard discharge Current4A
Max. Discharge Current20A
Discharge Cut-off Voltage9.0V
EnvironmentalCharge Temperature0℃~45℃
Discharging-10℃~65℃
Storage temperature-5℃~35℃
Storage Humidity≤75% RH
Water Dust ResistanceIP50
MechanicalCellSinge cell + PCM
HousingExpoxy board + PVC
Cell Dimension(L*W*H*)TBD
PCMIncluded
Switch/ButtonIncluded
Indicator/screenIncluded
N.W.:Approx. 1.2kg

More details

12V 12ah lipo battery pack could be 7Ah 9Ah 15Ah 16Ah 20Ah, it's light weight and compact, it can save you much cost on the tooling cost of a new plastic case replace by epoxy board + PVC instead, this battery pack could be equipped with switch/button, indicator/screen, so it can be operated conveniently, this battery pack is very popular for Led light, billboard, lightbox, CCTV and ect.

Photo Exhibition

  • ups battery 12v 7ah

    12v 12ah battery,12v 20ah battery,batteries 12v 20ah,battery 12v 7ah,battery 12v 12ah,12v 7ah battery,12v 9ah battery,battery 12v 9ah,lithium ion battery 12v 12ah,12v 16ah battery,12v 7ah lithium battery,ups battery 12v 7ah,ups battery 12v 9ah,tianneng battery 12v 20ah,12v 15ah battery
